Halogen-Free Flame Retardant Environmental Protection Heat Shrinkable Tube
Halogen-Free Flame Retardant Environmental Protection Heat Shrinkable Tube by using high energy electron beam bombardment of crosslinking polyolefin environmental protection heat shrinkable materials, belong to the environment friendly, when burning do not produce poison gas and harmful material, has the flame retardant, insulation, environmental protection, soft contraction fast, stable performance, and many other advantages. Pass 600V, 300V Certificate.
Standard color |
Black |
White |
Red |
Yellow |
Green |
Blue |
Purple |
Gray |
Brown |
Iron oxide red |
| Color nuber | 186U | 103U | 3288U | 646U | 2735U | 427U | 483U | 484U | ||
| Color standard |
Feature
Performance |
Unit |
Performance index |
Test method |
|
| Tensile strength | MPa | ≥10.1(Before aging) | GB/T 1040 | |
| ≥7.31(After aging) | 158℃×168h | |||
| Elongation at break | % | ≥200(Before aging) | GB/T 1040 | |
| ≥100(After aging) | 158℃×168h | |||
| Heat-resisting impact | - | No sticky，No cracks | 250℃×4h | |
| Resisting cold bending | - | No cracks | -30℃×4h | |
| Breakdown strength | kv/mm | ≥15 | GB/T 1408 | |
| Voltage-resistance | Voltage600V | - | Pass | 2500V,60s No breakdown |
| Voltage300V | - | Pass | 1500V,60s No breakdown | |
| Volume resistivity | Ω.cm | ≥1 ×10^14 | GB/T 1410 | |
| Corrosion resistance | - | Pass | 158℃×168h | |
| copper stable | - | Pass | 158℃×168h | |
| Flame resistance | - | Pass | VW-1 | |
Size
Size |
Before shrink size（mm） |
After shrink size （mm） |
Package standard |
Applicability |
||
Inside diameter |
Wall thickness |
Inside diamete |
Wall thickness |
Meter/Roll |
||
| 0.6 | 0.9±0.2 | 0.20±0.05 | ≤0.40 | 0.33±0.10 | 200 | 0.5~0.7 |
| 0.8 | 1.1±0.2 | 0.20±0.05 | ≤0.50 | 0.33±0.10 | 200 | 0.6~0.8 |
| 1.0 | 1.5±0.2 | 0.20±0.05 | ≤0.65 | 0.36±0.10 | 200 | 0.75~0.9 |
| 1.5 | 2.0±0.2 | 0.20±0.05 | ≤0.85 | 0.36±0.10 | 200 | 0.95~1.4 |
| 2.0 | 2.5±0.2 | 0.25±0.05 | ≤1.00 | 0.45±0.10 | 200 | 1.1~1.8 |
| 2.5 | 3.0±0.2 | 0.25±0.05 | ≤1.30 | 0.45±0.10 | 200 | 1.4~2.3 |
| 3.0 | 3.5±0.2 | 0.25±0.05 | ≤1.50 | 0.45±0.10 | 200 | 1.6~2.7 |
| 3.5 | 4.0±0.2 | 0.25±0.05 | ≤1.80 | 0.45±0.10 | 200 | 1.9~3.2 |
| 4.0 | 4.5±0.2 | 0.25±0.05 | ≤2.00 | 0.45±0.10 | 200 | 2.1~3.6 |
| 4.5 | 5.0±0.2 | 0.25±0.05 | ≤2.30 | 0.56±0.10 | 100 | 2.4~4.0 |
| 5.0 | 5.5±0.2 | 0.30±0.08 | ≤2.50 | 0.56±0.10 | 100 | 2.6~4.5 |
| 5.5 | 6.0±0.2 | 0.30±0.08 | ≤2.75 | 0.56±0.10 | 100 | 2.85~5.0 |
| 6.0 | 6.5±0.2 | 0.30±0.08 | ≤3.00 | 0.56±0.10 | 100 | 3.1~5.4 |
| 7.0 | 7.5±0.3 | 0.30±0.08 | ≤3.50 | 0.56±0.10 | 100 | 3.7~6.3 |
| 8.0 | 8.5±0.3 | 0.30±0.08 | ≤4.00 | 0.56±0.10 | 100 | 4.2~7.2 |
| 9.0 | 9.5±0.3 | 0.30±0.08 | ≤4.50 | 0.56±0.10 | 100 | 4.7~8.0 |
| 10 | 10.5±0.3 | 0.30±0.08 | ≤5.00 | 0.56±0.10 | 100 | 5.2~9.0 |
| 11 | 11.5±0.3 | 0.30±0.08 | ≤5.50 | 0.56±0.10 | 100 | 5.7~10 |
| 12 | 12.5±0.3 | 0.30±0.08 | ≤6.00 | 0.56±0.10 | 100 | 6.2~11 |
| 13 | 13.5±0.3 | 0.35±0.10 | ≤6.50 | 0.69±0.10 | 100 | 6.7~12 |
| 14 | 14.5±0.3 | 0.35±0.10 | ≤7.00 | 0.69±0.10 | 100 | 7.3~13 |
| 15 | 15.5±0.4 | 0.35±0.10 | ≤7.50 | 0.69±0.10 | 100 | 7.8~14 |
| 16 | 16.5±0.4 | 0.35±0.10 | ≤8.00 | 0.69±0.10 | 100 | 8.3~15 |
| 17 | 17.5±0.4 | 0.35±0.10 | ≤8.50 | 0.69±0.10 | 100 | 8.8~16 |
| 18 | 19.0±0.5 | 0.35±0.10 | ≤9.00 | 0.69±0.10 | 100 | 9.3~17 |
| 20 | 22.0±0.5 | 0.40±0.12 | ≤10.0 | 0.83±0.15 | 100 | 10.4~19 |
| 22 | 24.0±0.5 | 0.40±0.12 | ≤11.0 | 0.83±0.15 | 100 | 11.4~21 |
| 25 | 26.0±0.5 | 0.45±0.15 | ≤12.5 | 0.89±0.15 | 50 | 12.9~24 |
| 28 | 29.0±0.5 | 0.45±0.15 | ≤14.0 | 0.89±0.15 | 50 | 14.4~27 |
| 30 | 31.5±1.0 | 0.50±0.15 | ≤15.0 | 1.00±0.15 | 50 | 16~29 |
| 35 | 36.5±1.0 | 0.50±0.15 | ≤17.0 | 1.00±0.15 | 50 | 18~34 |
| 40 | 41.5±1.0 | 0.55±0.15 | ≤20.0 | 1.00±0.15 | 50 | 21~39 |
| 45 | 46.5±1.0 | 0.55±0.15 | ≤22.5 | 1.00±0.15 | 25 | 23.5~44 |
| 50 | ≥50 | 0.55±0.15 | ≤25.0 | 1.10±0.15 | 25 | 26~49 |
| 60 | ≥60 | 0.60±0.15 | ≤30.0 | 1.20±0.15 | 25 | 35~55 |
| 70 | ≥70 | 0.65±0.15 | ≤35.0 | 1.30±0.20 | 25 | 40~65 |
| 80 | ≥80 | 0.65±0.15 | ≤40.0 | 1.30±0.20 | 25 | 45~75 |
| 90 | ≥90 | 0.65±0.15 | ≤45.0 | 1.30±0.20 | 25 | 50~85 |
| 100 | ≥100 | 0.65±0.20 | ≤50.0 | 1.30±0.20 | 25 | 55~95 |
| 120 | ≥120 | 0.65±0.20 | ≤60.0 | 1.30±0.20 | 25 | 65~115 |
| 150 | ≥150 | 0.65±0.20 | ≤70.0 | 1.30±0.20 | 25 | 80~145 |
| 180 | ≥180 | 0.65±0.30 | ≤90.0 | 1.30±0.30 | 25 | 95~175 |
| 210 | ≥210 | 0.65±0.30 | ≤105.0 | 1.30±0.30 | 25 | 110~205 |
| 330 | ≥230 | 0.65±0.30 | ≤115.0 | 1.30±0.30 | 25 | 120~225 |
| 350 | ≥250 | 0.65±0.30 | ≤125.0 | 1.30±0.30 | 25 | 130~240 |
Product characterisitic
1.Halogen-free,low smoke,non-toxic,flame retardant
2.Shrinkable temperature：84-℃120℃
3.Shrinkable ratio：2：1
4.Rated temperature：-55℃-125℃
5.Soft,contranction fast,stable performance
Product user
1.Function：Electric insulation,solder rustproof,mechanical protection
2.Application：Electron,communiction,automobile,shipbuilding,aircraft manufacturing and other
